Controller: FANUC 0i-TF
Table dia.: 1600mm
Max. swing: 2000mm
Max. turning dia.: 1800mm
Max. turning height: 1200mm
X axis travel (left-right): -3593~+1103mm (incl. ATC travel)
Z axis travel (up-down): 900mm
Vertical travel of cross rail: 800mm
Table speed: 1~250rpm (2 steps)
Spindle motor: α40i (37/45kW)
BT50 / 12ATC (Two sides restraint)
Tool magazine high pressure air blast
X/Z axes Heidenhain linear scales
Tool off set
High pressure pump (20bar)
Air conditioner for electrical cabinet
Hydraulic tank cooler
Spindle oil cooler
Oil skimmer
Chip conveyor
O.D. tool holder: 11 pcs
I.D. tool holder: 2 pcs short, 1 pc long
