CNC SYSTEM FANUC 18iTB
Table 1600mm
Max. Swing 2000mm
Max. Load capacity 10Ton
Min. Boring 340mm
Turning height 1750mm
Ram stroke 1000mm
Crossrail 250 x 3 steps 750mm
Table speed 1 ~ 63RPM (Low)
Table speed 4 ~ 250RPM (High)
Table motor 37 / 45Kw
Ram size 240mm x 240mm
Milling spindle speed 2000RPM
Milling spindle motor 15 / 18.5Kw
ATC 16 BT. 50
Floor space 5085mm x 6550mm x 6428mm
Chip conveyor
90 deg. Angle head
Extension head
