CONTROLLER SIEMENS 840D

Table diameter:
Max. wheel diameter:
Gearwidth:
Max. module:
2000 mm
3000 mm
1000 mm
24/ 28
Table load capacity max.: 25000 kg
z-axis:
Y-axis:
X-axis:
1400 mm
450mm
970mm
·Max. helical angle: 45 °
Table l;>ore diameter: 600mm
Distanèe cutter centre - table centre: 200 - 2200 mm
. Diameter of hob: 400 mm
Cutter length max.: 600mm
Hob turning speeds: 25 - 150 U/min
Internal head geared:
-with the smalle􀀸t internal 0 980mm
-with the largest internal 0 2200mm
External head geared:
-with the smallest external 0 950mm .
-with the largest external 0 2800mm
