Between columns 4000
Height 3550
XYZW 10250/5000/1000/2500
Table size 3000 x 10300
Max. Load 50,000 kgs
Spindle speed 2500 rpm
Spindle motor AC 30/37kw
Fanuc 31iB

** Optional accessories
Automatic tool changer (ATC), 90Tools
Automatic attachment changer (AAC) for 4 ports
Universal angular attachment (U.A.A) - 600mm
Right angular attachment (R.A.A) - 350 mm
Extension attachment (E.A) - 600mm
TSC (coolant-thru-the-spindle device) : 30 bar
Chip conveyor (2 Pcs) & chip bucket(2 Pcs)
Linear scale for X.Y,Z.W-axis
