SPECIFICATIONS:
Bar Capacity............3"
Chuck Size............12"
Spindle Speed............3000 RPM
Spindle Motor............40 HP
X-Axis Travel............11.83"
Z-Axis Travel............43.11"
Y-Axis Travel............+/- 4.13"
B-Axis Movement............225 Degrees - 1 degree
C-Axis Spindle Index............0.001 Degree
Spindle Nose / Spindle Bore / Bar Capacity............A2-8" / 3.46" / 3.46"
Rapid Rate Z Axis............1181 IPM
Turret Tools............40 Station ATC
Rapid Rate X Axis............1181 IPM
Turning Diameter - Maximum............24 "
Turning Length - Maximum............39.3"
Swing - Maximum............24"
Rotary Tool Spindle Nose............63mm short taper
Rotary Tool Spindle Speed............6,000 RPM
Rotary Tool Spindle............20 HP
Dimensions - Approximate............155"(L-R) x 89"(F-B) x 107"(H)
Weight - Approximate............20,000 LBS

Mazak Integrex 400-IIY EQUIPPED WITH:
- Mazatrol
- Chip Conveyor
- Tool Presetter
- Tailstock
- Live Tooling
- Y Axis
- 5 Axis
